Description
ForeCast™ SS304 standard wire snake guides will be sublime on your budget minded rod build. This snake guide is plated for superb wear. ForeCast™ standard wire snake guides are offered in eight sizes to allow the rod builder to match guide sizes to any application needed. Matching the ForeCast™ standard wire snake guides to any of the ALPS™ light XN, medium XN, and ForeCast™ medium UD stripper guides is easy. Constructed from SS304 stainless steel then hard chrome plated provides superb corrosion resistance. Standard with the ForeCast™ standard wire snake guides include pre-grounded feet to simplify wrapping on any blank.
| GUIDE SIZE | WIRE DIAMETER (MM) | LENGTH (MM) | LENGTH (IN) | HEIGHT (MM) | HEIGHT (IN) | WEIGHT (GRAINS) | WEIGHT (OZ) |
|---|---|---|---|---|---|---|---|
| 2/0 | 0.75 | 18.70 | 0.737 | 5.98 | 0.235 | 1.5 | 0.003 |
| 1/0 | 0.75 | 20.20 | 0.795 | 6.75 | 0.265 | 1.7 | 0.003 |
| 1 | 0.75 | 20.80 | 0.820 | 7.40 | 0.292 | 1.9 | 0.004 |
| 2 | 0.95 | 22.15 | 0.872 | 8.27 | 0.325 | 3.0 | 0.006 |
| 3 | 0.95 | 23.00 | 0.900 | 9.40 | 0.370 | 3.2 | 0.007 |
| 4 | 1.00 | 26.25 | 1.030 | 10.68 | 0.420 | 4.4 | 0.010 |
| 5 | 1.00 | 28.10 | 1.100 | 11.50 | 0.452 | 4.8 | 0.010 |
| 6 | 1.20 | 31.00 | 1.220 | 12.10 | 0.475 | 7.8 | 0.017 |
